KC HiLiTes Gravity® LED Pro6 5-Light 32" Universal Combo LED Light Bar without Light Mounts - #91306

The Details

FEATURES
-Powered by Gravity® LED G6 optical inserts – efficient, powerful, patented
-G6 LED Optics available in Spot, Driving, Wide-40 Beam Patterns
-High output, low amperage draw
-Available in 20" 3-Ring, 26" 4-Ring, 32" 5-Ring, 39" 6-Ring, 45" 7-Ring, 50" 8-Ring, and 57" 9-Ring widths (Vehicle specific kits also available)
-Patent-pending Infinity Ring™ system enables you to configure the LED bar to be
straight, radius or hybrid radius positions (Patent-pending Application 14/704,736)
-Signature KC modular design is expandable to different widths
-Modular beam optics allow you to change and rotate beams to customize

LIGHT PERFORMANCE
-Raw Lumens: 20" = 6,900 lm, 26" = 9,200 lm, 32" = 11,500 lm, 39" = 13,800 lm, 45" = 16,100 lm, 50" = 18,400 lm, 57" = 23,009 lm,
-Lux @ 10 Meters: 20" = 2,794 lx, 26" = 3,425 lx, 32" = 4,200 lx, 39" = 5,150 lx, 45" = 6,100 lx, 50" = 6,700 lx, 57" = 7,500 lx
-Candela: 20" = 279,400 cd, 26" = 342,500 cd, 32" = 420,000 cd, 39" = 515,000 cd, 49" = 610,000 cd, 50" = 670,000 cd, 57" = 750,000 cd
-Beam Distance (Meters): 20" = 1,057m, 26" = 1,170m, 32" = 1,296m, 39" = 1,435m, 45" = 1,562m, 50” = 1,637m, 57” = 1,732m

SPECIFICATIONS
-Wattage: 20" = 60W, 26" = 80W, 32" = 100W, 39" = 120W, 45" = 140W, 50" =160W, 57" = 180W
-Amp Draw: 5.0-14.67A
-LED Source: Cree XPL HD LED
-LED Color: 5000K
-Voltage: 9-32V
-Dimensions: 20” = H - 6.06" x D - 3.33" x W - 20.325" (Straight) / 20.301" (Curved) | 26” = H - 6.06" x D - 3.33" x W - 26.575" (Straight) / 26.556" (Curved) | 32” = H - 6.06" x D - 3.33" x W - 32.875" (Straight) / 32.708" (Curved) | 39” = H - 6.06" x D - 3.33" x W - 39.125" (Straight) / 38.871" (Curved) | 45” = H - 6.06" x D - 3.33" x W - 45.38" (Straight) / 44.999" (Curved) | 50” = H - 6.06" x D - 3.33" x W - 51.625" (Straight) / 51.086" (Curved) | 57” = H - 6.06" x D - 3.33" x W - 57.625" (Straight) / 57.128" (Curved)

Parts Included With Pro6 LED Light Bar System
-(1) Pro6 LED Light Bar
-Light Covers - Black with Yellow KC Logo
-Mounting Brackets and Hardware in Vehicle specific kits
***Note: Light Bar Mounting Brackets not included with Universal Light Bar Systems
-Deluxe Plug-N-Play Wiring Harness with 30 amp LED Switch

PERFORMANCE Gravity® LED OPTICS
Patented Gravity LED G6 optical inserts provide exceptional efficiency and light output. Pro6 light bars ship with a combination of driving and Wide-40 G6 optical inserts.

INFINITY RING™ SYSTEM
The Infinity Ring™ system provides a race-proven, adjustable linking system featuring expandable widths, modular beam shape and a radius or straight setting between each ring.

UNIVERSAL END MOUNT SYSTEM
The Pro6 LED light bar comes ready to fit most standard LED bar widths and is designed with high-strength aluminum end mounts. This universal mounting design easily attaches to KC mounts on your Jeep, Truck or UTV.

RACE PROVEN STRENGTH & DURABILITY
Inspired by endurance racing and tested by KC athletes worldwide, the Pro6 is set to break all performance barriers while providing the most durable, reliable and scalable LED light bar design available today.
